Name: AUDIOENGINE HD3 BLUETOOTH HOME MUSIC SYSTEM - WALNUT
Brand: Audiopacific
SKU: AUDIOENGINE-HD3-BLUETOOTH-HOME-MUSIC-SYSTEM-WALNUT
Price: 349.00 USD
Availability: OutOfStock

AUDIOENGINE HD3 BLUETOOTH HOME MUSIC SYSTEM - WALNUT

Roll over image to zoom in Click on image to zoom

FedEx shipping & Convoy Order Protection included with all Speakers and Turntables

Overview

Audioengine HD3 Bluetooth Speaker System

Enjoy your audio from nearly any source with this pair of walnut Audioengine HD3 Bluetooth Speaker System. They feature Bluetooth with aptX HD for wireless connectivity, stereo RCA and 1/8" inputs for traditional wired devices, and a micro-USB input for a dedicated input from your computer. The HD3 has a 2-way design with two built-in, 15W per channel amplifiers. Each speaker sports a 2.75" Kevlar woofer and a 0.75" silk dome tweeter.

No Missed Connections

Connect to the HD3 any way you like: wirelessly or wired, digital or analog. Stream your music library, TIDAL, Spotify, Pandora, YouTube, etc. to the HD3 from just about anywhere in your house (within 100') without dropouts. Wireless setup is designed for simplicity and only takes about a minute. And if you're using the HD3 on your desktop, connect it with a USB cable. The USB input bypasses your computer's built-in headphone jack for an enhanced listening experience. If you're not keen on USB or wireless, you can still use any stereo RCA or 1/8" audio cable to connect.

Expandability

The HD3 is expandable, so if you want deeper bass, just connect your subwoofer.

Plug In Your Headphones

The HD3 includes a dedicated headphone output on the front panel, so you can listen without waking the neighbors. Its headphone amplifier is designed to deliver quality sound that drives even the most demanding headphones.

Retro-Forward Design

The HD3 features aluminum trim accents and detachable magnetic grilles designed to blend with any décor.

Built-In Amplifiers

Built-in power amplifiers save space and eliminate the need to connect the HD3 to a stereo receiver or external power amp. Simply plug the left speaker into a power outlet and connect the included speaker wire from the left to the right speaker. All internal components of the HD3 are designed and tuned together for a more uniform sound than traditional separate speakers and amplifier.

Integrated Design

The speaker cabinets, drivers, bass port designs, amplifiers, and passive crossovers are all tuned together specifically for the HD3. This is designed to provide for a more efficient system that requires less power than passive speakers and a separate integrated amplifier or similar A/V components.

Built-In B1 and D1

Features from the Audioengine B1 aptX HD Bluetooth receiver and D1 24-bit DAC are combined in the HD3 to help make it a complete digital audio system.

Bluetooth and aptX HD

The HD3 is designed to easily connect to any of your devices that have Bluetooth, but for enhanced sound quality, use a device that supports Bluetooth aptX HD. For Apple devices that don't have aptX HD, such as the iPad or iPhone, Apple generally uses the AAC codec. It sounds good as well, and you'll get the extra benefit of the upsampling 24-bit DAC.

Extended Wireless Range

Through signal management circuitry and antenna tuning, the HD3 offers a solution that has up to three times the range of standard Bluetooth for multi-room use with no degradation in audio quality.

24-Bit DAC

The HD3 Bluetooth receiver and USB input both utilize the PCM 5102 DAC, which is designed for low-noise and high-fidelity. The PCM 5102 is used as an upsampling DAC and will pad all bit depths to 24-bit, achieving a higher signal-to-noise ratio and lower noise floor. Due to the high signal-to-noise specs of the PCM 5102, the fact that digital signal is upsampled to 24-bits – as well as the added benefit of onboard triple-redundancy power source conversion and filtering – the HD3 Bluetooth implementation presents low noise and low distortion characteristics with a noticeable improvement over other Bluetooth devices.

HD3 Headphone Amplifier

The HD3 contains a headphone amplifier based on the OPA2134 low-noise opamp. This amp is designed to provide low-impedance, high-fidelity audio and a 2V output, which can drive a wide range of headphones.

Amplifier Design

The amplifiers in the HD3 are located in the left speaker and are a class A/B analog monoblock design. This is a more traditional speaker/amplifier configuration, which is designed to provide quality audio and greater flexibility. All circuit boards for the power and preamp sections are vertically mounted for enhanced mechanical shock protection.

Driver Designs

The HD3 uses ferrofluid-cooled silk dome tweeters with neodymium magnets. Silk tweeters are fashioned to hold up well under high power, and the edge-driven design gives a smooth response. The woofers are Kevlar-woven glass-aramid composite with rubber surrounds. Kevlar is designed for strength, so the woofer can retain its shape when being driven at high levels.

Magnetic Shielding

The speaker drivers in the HD3s are directly magnetically shielded.

Additional Features

RCA and 1/8" audion inputs for easy connection to various audio sources, including a turntable or TV
USB input for computer connection with up-sampling 24-bit DAC
0.75" thick MDF cabinets with wood veneer

In The Box

Audioengine HD3 Bluetooth Speaker System (Walnut, Pair)
2 x Grilles
5' Mini-Jack Audio Cable
5' USB Cable
6.5' 16 AWG Speaker Wire
Antenna
Microfiber Speaker Bags
Microfiber Cable Bag
Microfiber Power Supply Bag
Power Supply
AC Power Cable
Limited 3-Year Warranty

Specs

GENERAL SPECIFICATIONS

Type
Powered Bluetooth aptX HD speaker system

Amplifier Type
Class AB

Power Output
60 W peak power total (15 W RMS / 30 W peak per channel), AES

Drivers
2.75” aramid fiber woofers
0.75“ Silk dome tweeters

Inputs
3.5 mm stereo mini-jack, RCA L/R, USB, Bluetooth

Outputs
RCA variable line-out, 3.5 mm mini-jack headphone out

Input Voltages
110-240 V 50/60 Hz auto-switching

SNR
>95 dB (typical A-weighted)

THD+N
<0.05% at all power settings

Crosstalk
<50 dB

Frequency Response
65 Hz-22 kHz ±2.0 dB

Input Impedence
5K ohms unbalanced

Protection
Output current limiting, thermal over-temperature, power on/off transient protection

Power Consumption
Idle: 10W

BLUETOOTH SPECIFICATIONS

Internal D/A Converter
PCM 5102

Input Bit Depth
24 bit (padded)

Bluetooth Receiver Type
Bluetooth 5.0

Supported Codecs
aptX HD, aptX, AAC, SBC

Wireless Operation Range
Up to 100 ft (30 m) typical

Input Data Rate
Determined by Bluetooth

Wireless Latency
~30 milliseconds (ms)

USB SPECIFICATIONS

Connector Type
Micro-USB

USB Device Class

USB 1.1 or above

Input Bit Depth
24 bit (padded)

Input Sample Rate
44.1 kHz/48 kHz

HEADPHONE AMP SPECIFICATIONS

Headphone Amp Type
OPA2134

Full-scale Headphone Output Level
2.0 V RMS

Output Impedence
2 ohms

Recommended Headphone Impedence Level
10 ohms to 10K ohms

WEIGHTS AND MEASUREMENTS

Dimensions (HWD)
Each speaker – 7″(17.8 cm) x 4.25″ (10.8 cm) x 5.5″ (14 cm)

Weight
Left (powered) – 4 lb (1.8 kg)
Right (passive) – 3.4 lb (1.5 kg)

Total Shipping Weight
10 lb (4.6 kg)

Shipping Box Dimensions (LWH)
11.75″ (30 cm) x 8.8″ (22.5 cm) x 11.6″ (29.5 cm)

ENVIRONMENTAL REQUIREMENTS

Operating temperature: 32 degrees F to 95 degrees F
Non-operating temperature: -4 degrees F to 113 degrees F
Relative humidity: 5% to 95% non-condensing

MATERIALS AND CONSTRUCTION

0.7″ (18 mm) thick MDF cabinets with real wood veneer

0.75″ (20 mm) silk dome tweeters with neodymium magnets
2.75″ (70 mm) aramid fiber woofers with advanced voice coils
